| REMARKS
|
1.
As far possible, nominal diameter in parethesos should be avold
be avoid from ues. |
| |
2.
The diamensional toleramce shall confirm to JIS B2203 |
| |
3.
The flange gasket surface is based on large raised facing facing
specifird in JIS |
| |
|
B2202. But,
if necessary, facings other than the large eaised facing specified
in JIS B2201 can be designated by customers. |
| |
4. Size d
is an example of pipe thickness for schedule 40 of JIS G3454
and JIS B3456. |
| |
|
When other
size is necessary, customers can order it at will. |
| |
5. Refer to
JIS B2216. |
